Description
Features
- 2 megapixel CMOS sensor
- Digital resolution: 1080P (1920x1080), 960H (960x576)
- Frame rate: 25 fps @ 1080P (CVI/TVI/AHD), 25 fps @ 960H (CVBS)
- 4-in-1 switchable output
- Day/night mode with removable mechanical filter
- 0.001 lux F1.6 (color) / 0 lux with IR on
- Smart IR: 2 IR LEDs, 60 meters
- Motorized lens 2.7 ~ 13.5 mm
- Viewing angle: 108°~30°(H), 56°~17°(V), 131°~35°(D)
- Auto focus mode
- OSD via coaxial (1080P video up to 700 meters only)
- Image modes: BLC, HLC, WDR 130dB, 3D-NR, Mirror
- Automatic white balance and area balance
- Automatic and manual gain control
- Supports 8-zone privacy mask including a microphone
- PoC Power (CVI only): can be powered via a single coaxial cable via XVR with PoC function
- Power supply: 12V DC (±30%) / PoC (CVI)
- Consumption: 6.4W (12V) / AT (PoC)
- Storage temperature -30°C ~ +60°C
- Operating temperature -30°C ~ +60°C
- Relative humidity: <95% (non-condensing)
- IP67 protection rating
- Metal housing
- Dimensions: Ø122 x 104.8mm
- Weight: 600g
- 3 AXES: 0°~360°(PAN), 0°~78°(TILT), 0°~360°(Rotation)
