Description
Features
- 1/1.2" 8-megapixel CMOS sensor
- Compression formats: H.265+, H.265, H.264+, H.264, MJPEG
- Digital resolution: 8MP (3840x2160), 6MP (3072x2048), 5MP (3072x1728), 5MP (2592x1944), 4MP (2688x1520), 3MP (2048x1536), 3MP (2304x1296), 1080P (1920x1080), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 8MP (1~25fps)
- Stream 2: D1 (1~25fps)
- Stream 3: 1080P (1~25fps)
- 24-hour color mode
- Smart Light: 4 warm LEDs, 50 meters
- 0.0005lux F1.0
- 2.8mm fixed lens
- Viewing angle: 112°(H), 61°(V), 131°(D)
- Image modes: BLC, HLC, WDR 140dB, 3D-NR, Mirror, Defog
- White balance with 6 modes
- Automatic and manual gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI) and 8-zone privacy mask
- Intelligent Video Detection (IVS): Abandoned/lost object detection
- Heat map support
- Perimeter protection with line crossing detection, intrusion detection, fast motion detection (all three modes support human/vehicle classification), loitering detection, people gathering detection, and parking detection
- Face detection with three capture methods
- People counting: Counting people entering/exiting and number of people passing; displays and generates annual/monthly/weekly/daily reports; supports people counting in an area and establishes 4 rules
- Includes a microphone
- 1 RCA audio input / 1 output
- 1 alarm input / 1 output
- MicroSD card slot up to 256GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, HTTPS, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, 802.1x, SNMP
- Compatible with ONVIF (Profile S/G/T), CGI, P2P, Milestone, SDK and API
- Up to 20 users
- Remote viewing via IE8, Chrome, Firefox browsers
- Smart PSS, DSS, DMSS management software
- Compatible with iOS and Android mobile devices
- Power supply: 12V DC (±30%)
- Consumption: 11.1W
- Supports PoE (802.3af)
- PoE consumption: 12.1W
- ePoE support
- Storage temperature -40°C ~ +60°C
- Operating temperature -40°C ~ +60°C
- Relative humidity: <95%
- IP67 protection rating
- Metal casing
- Dimensions: 94.4 (L) x 84.7 (H) x 288.4 mm
- Weight: 1.15 kg
- 3 AXES: 0°~360°(PAN), -20°~90°(TILT), 0°~360°(Rotation)
