Description
Features
- 2 megapixel 1/2.8" CMOS image sensor
- H.265+, H.264+, H.265, H.264 and MJPEG video compression
- Resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), CIF (352x288)
- Stream 1: 1080P, 1.3MP, 720P (1~25/30fps)
- Stream 2: D1, CIF (1~25/30fps)
- Stream 3: 1080P, 1.3MP, 720P (1~25/30fps)
- Day/night mode with removable mechanical filter (ICR)
- 0.002 lux F1.6 (color), 0.0002 lux F1.6 (B/W), 0 lux IR on
- Smart IR: 2 IR LEDs + 1 white LED, up to 30 meters
- 4 mm fixed lens
- Viewing angle: 86.8° (H), 45.9° (V), 102.4° (D)
- Image modes: BLC, HLC, Digital WDR, 2D/3D-NR, Digital Defog
- White balance with 8 modes
- Automatic and manual gain control
- Supports video sensor and regions of interest (ROI)
- Perimeter protection with line crossing detection and intrusion detection (with person/vehicle classification)
- Horizontal positioner: 0° ~ 355°
- Vertical positioner: -15° ~ 90°
- Manual speed: 0.1° ~ 80°/sec. (H), 0.1° ~ 56°/s. (V)
- Preset speed: 81°/sec. (H), 43°/sec. (V)
- 300 presets
- MicroSD card slot up to 256GB (card not included)
- Two-way audio with microphone and speaker
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, ARP, SNMP v1/v2c/v3 (MIB-2), RTCP, RTMP
- Remote viewing with browsers (IE7, Chrome 42, Firefox 52 and Safari) and IOS and Android smartphones
- Up to 20 users
- DMSS management software
- Interoperability: ONVIF S/G/T, CGI
- Power supply: 12V DC/2A (±10%), supports PoE
- Consumption: 4.5W (10W with IR illumination on)
- Operating conditions: -30°C ~ +60°C, humidity <95%
- IP66 protection rating
- Lightning-proof 2KV
- Dimensions: 124.1 (W) x 271.7 (H) x 142.5 mm
- Weight: 1.1 kg
- Includes charger and bracket
