Description
- 1/2.8" 2-megapixel CMOS image sensor
- Smart H.265+, Smart H.264+, H.265, H.264 and MJPEG video compression
- Resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 1080P, 1.3MP, 720P (1~25/30 fps)
- Stream 2: D1, CIF, VGA (1~25/30 fps)
- Stream 3: 1080P, 1.3MP, 720P (1~25/30 fps)
- Day/night mode with removable mechanical filter (ICR)
- 0.05 lux F1.6 (colour), 0.005 lux F1.6 (B/W), 0 lux IR On
- Smart Dual Light: 2 IR LEDs (up to 50 m) + 2 warm white LEDs (up to 30 m)
- 5X optical zoom: 2.7 ~ 13.5 mm
- Viewing angle: 99.6°~31.5°(H), 53°~17.8°(V), 118.8°~36.2°(D)
- Automatic, semi-automatic and manual focus
- Fixed iris control
- 16X digital zoom
- Image modes: BLC, HLC, WDR 120dB, 2D/3D-NR, EIS, Digital Defog
- White balance with 8 modes
- Automatic and manual gain control
- Supports video sensor and regions of interest (ROI)
- Perimeter protection with line crossing detection, intrusion detection (with people/vehicle classification), fence crossing detection, loitering detection, abandoned/lost object detection, fast movement detection, parking detection, people gathering detection, etc.
- SMD 3.0 motion detection
- Horizontal positioner: 0° ~ 355°.
- Vertical positioner: -15° ~ 90
- Manual speed: 0.1° ~ 36°/sec (H), 0.1° ~ 25.8°/sec (V)
- Preset speed: 35.7°/sec (H), 27.1°/sec (V)
- 300 presets
- Built-in microphone and speaker
- 1 audio input / 1 audio output
- Built-in active deterrence via flashing white light with three flashing frequencies and up to 11 alarm tones
- MicroSD card slot up to 512 GB (card not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: FTP, RTMP, IPv6, Bonjour, IPv4, DNS, RTCP, PPPoE, NTP, RTP, 802.1x, HTTPS, SNMP, TCP/IP, DDNS, UPnP, NFS, ICMP, UDP, IGMP, SMB, HTTP, SSL, DHCP, SMTP, Qos, RTSP, ARP
- Interoperability: ONVIF (S/G/T), CGI, SDK, P2P
- Compatible with IE, Chrome, Firefox and Safari browsers
- Compatible with IOS and Android devices
- Up to 20 users
- DMSS, DSS Pro management software
- Power supply: 12V DC, 1.5A (±25%) / PoE (802.3af)
- Power consumption: 3W (basic), 12W (maximum)
- Operating temperature: -30°C ~ +60°C
- Relative humidity ≤95%.
- IP66 degree of protection
- Dimensions: 140 (L) x 236.1 (H) x 142.6 mm
- Net weight: 1.1 kg
- Gross weight: 1.7 kg
- Wall bracket included
- Power supply not included
