Description
Specifications
- 1/2.7" 5-megapixel CMOS sensor
- Digital resolution: 5MP (2880x1620), 4MP (2560x1440), 1080P (1920x1080), 960H (960x576)
- Frames per second: 25 fps @5MP (CVI), 25 fps @4MP (CVI/TVI/AHD), 25 fps @1080P (CVI)
- 4-in-1 output switchable via OSD menu
- Day/night mode with removable mechanical filter (ICR)
- 0.005 lux F1.6 (color) / 0 lux IR On
- Smart IR: 3 LEDs, up to 30 meters
- 2.8 mm fixed lens
- Viewing angle: 111°(H), 58°(V), 132°(D)
- OSD via coaxial (5MP video up to 700 meters)
- Image modes: BLC, HLC, digital WDR, 2D-NR, Mirror
- Automatic and manual white balance
- Automatic and manual gain control
- 8-zone privacy mask
- Built-in microphone
- PoC power (CVI only): can be powered by a single coaxial cable via the XVR with PoC function, eliminating the need for an external power supply, thus reducing installation time and cost.
- Power supply: 12V DC (±30%)
- Consumption: 3.7 W (max.)
- Storage temperature: -40°C ~ +60°C (-40°F ~ +140°F)
- Operating temperature: -40°C ~ +60°C (-40°F ~ +140°F)
- Relative humidity: <95% (non-condensing)
- IP67 protection rating
- Metal casing
- Dimensions: 69.7 (W) x 70 (H) x 166.6 mm
- Weight: 330 g
- 3AXIS: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(Rotation)
