Description
Features
- 1/2.7" 5-megapixel CMOS sensor
- Digital resolution: 5MP (2880x1620), 4MP (2560x1440), 1080P (1920x1080), 960H (960x576)
- Frames per second: 25 fps @ 5MP (CVI), 25 fps @ 4MP (CVI / TVI / AHD), 25 fps @ 1080P (CVI)
- 4-in-1 output switchable via DIP switch
- Day/night mode with removable mechanical filter (ICR)
- 0.001 lux F1.6 (color) / 0 lux IR on
- Smart IR: 2 LEDs, up to 30 meters
- Motorized lens 2.7 ~ 13.5 mm
- Viewing angle: 31.4° ~ 113° (H), 17.6° ~ 58° (V), 36° ~ 138° (D)
- Auto focus control
- 4X digital zoom
- OSD via coaxial (5MP video up to 700 meters)
- Imaging modes: BLC, HLC, HLC-Pro, WDR 120dB, 3D-NR, digital defog, mirror
- Automatic and manual white balance
- Automatic and manual gain control
- Supports 8-zone rectangular privacy mask
- Power: 12V DC (± 30%)
- Consumption: 6.6 W (max.)
- Storage temperature -30°C ~ +60°C
- -30°C ~ +60°C operating temperature
- Relative humidity: <95% (non-condensing)
- IP67 protection rating
- IK10 vandal protection
- Metal casing
- Dimensions: Ø122 x 88.9 (H) mm
- Weight: 470 g
- 3AXIS: 0° ~ 355° (PAN), 0° ~ 75° (TILT), 0° ~ 355° (Rotation)
