Description
Specifications
- 5 technologies: IP, HDCVI, HDTVI, AHD and CVBS analog cameras with automatic signal recognition
- 4 BNC 1080N channels (BNC inputs can be converted to IP)
- 1 IP channel at 2MP (added to BNC inputs)
- Video compression: AI, H.265+, H.265, H.264+, H.264
- HDMI (1080P) and VGA (1080P) video output
- Output division: 1, 4 (IP mode off); 1, 4, 6 (IP mode on)
- 1 RCA input / 1 RCA audio output
- Two-way audio via RCA channel
- Audio compression: G.711a, G.711u, PCM
- Recording resolution: 1080N, 720P, 960H, D1, CIF
- Maximum incoming bandwidth 32 Mbps
- Primary stream: 1080N, 720P, 960H, D1, CIF (1~25 fps)
- Secondary stream: CIF (1~15 fps)
- Recording modes: manual, scheduled, video detection, video loss, tampering, alarm, stop
- Recording intervals (1~60 min.), pre-recording (1~30 sec.) and post-recording (10~300 sec.)
- Independent video sensor configurable by camera (22x18 grid selectable), video loss detection and masking, diagnostics
- Playback up to 4 channels
- SMD Plus: 4 channels, person/vehicle classification
- Internal capacity for 1 SATA hard drive up to 6TB (sold separately)
- Multilingual on-screen menu with improved new graphical interface
- Possibility to update DAHUA camera firmware from the recorder itself
- Software and hardware watchdog
- Watermark to preserve video integrity
- RJ45 Fast Ethernet (100M) network port
- ONVIF 16.12 and CGI compatibility
- Remote access from web browser and iPhone, iPad, Android devices (EVO and TTS App)
- Email sending with attached photo in case of alarm
- FTP sending scheduled or on alarm
- Possibility to send alarms and be connected to an alarm reception software (C.R.A.) thanks to the free AlarmSpace software.
- Possibility of fixed or dynamic IP via DDNS Evolution service
- Communication ports: 2 USB 2.0 ports, 1 RS485 port
- Power supply: 12V DC, 1.5A (<4W, without drives)
- Storage temperature from -20°C ~ +70°C
- Operating temperature from -10°C ~ +45°C
- Relative humidity 0%~90%
- Dimensions: 260(W) x 47.6(H) x 237.9 mm
- Weight: 860 g
- Desktop installation
