Description
Specifications
- 1/1.8" 8-megapixel CMOS sensor
- Compression formats Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG
- Digital resolution: 8MP/4K (3840x2160), 4MP (2560x1440), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), CIF (352x288)
- Stream 1: 8MP/4K, 1080P, 1.3MP, 720P (1~25 fps)
- Stream 2: D1, CIF (1~25 fps)
- Stream 3: 1080P, 1.3MP, 720P (1~25 fps)
- Day/night mode with removable mechanical filter
- IR illumination up to 500 meters
- 0.005 lux F1.4 (color) / 0.0005 lux F1.4 (B/W), 0 lux IR On
- 40X optical zoom: 5.6 ~ 223 mm
- Viewing angle: 63.9°~2°(H), 37.2°~1.2°(V), 71.2°~2.4°(D)
- Automatic, semi-automatic and manual focus control
- Automatic, manual and fixed iris control
- 16X digital zoom
- Image modes: BLC, HLC, WDR 140dB, 2D/3D-NR, optical fog, image stabilizer
- White balance with 8 modes
- Automatic and manual gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI) and 4-zone privacy mask.
- Intelligent Video Detection (IVS): abandoned or lost object detection.
- White balance: Auto, Indoor, Outdoor, Tracking, Manual, Sodium lamp, Daylight, Street lamps.
- Automatic and manual gain control
- Support for video sensor, regions of interest (ROI) and 24-zone privacy mask.
- Intelligent Video Detection (IVS): abandoned/lost object detection.
- Artificial intelligence:
- Perimeter protection: Cross-line detection, intrusion detection (supports alarm with people/vehicle classification)
- Supports autotracking
- Support for video metadata with image capture and attribute extraction of human body, human face, motorized and non-motorized vehicles.
- Horizontal positioner: 0° ~ 360° continuous
- Vertical positioner: -30° ~ 90°, 180 auto-flip
- Manual speed: 0.1° ~ 240°/sec. (H), 0.1° ~ 100°/sec. (V)
- Preset speed: 240°/sec. (H), 120°/sec. (V)
- 300 DH-SD, Pelco-D/P presets (automatic recognition)
- 5 patterns, 8 tours (up to 32 presets per tour), 5 scans
- 1 BNC video output
- 1 audio input / 1 audio output
- 7 alarm inputs / 2 alarm outputs
- RS485 port
- MicroSD card slot up to 256 GB (card not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP v1/v2c/v3 (MIB-2), DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, ARP, RTCP, RTMP
- ONVIF S/G/T, CGI support
- Unicast / Multicast streaming method
- Up to 20 users
- Remote viewing with IE7+, Chrome42, Firefox52, Safari browsers
- Smart PSS, DSS, DMSS, Easy4ip, IVSS management software
- Compatible with IOS and Android smartphones
- Power supply: 36V DC /2.23A (±25%)
- Consumption: 30W (48W with IR illumination activated)
- Supports Hi-PoE
- Operating temperature: -40°C ~ +70°C
- Relative humidity: ≤95%
- IP67 protection rating
- 6KV lightning protection
- Metal housing
- Dimensions: Ø262 x 415.2 (H) mm
- Weight: 8.5 kg
- Wall bracket and power supply included
