Description

![]()

Features
- 8 megapixel 1/2” CMOS sensor
- Digital resolution: 4K/8MP (3840x2160), 6MP, 4MP
- Frames per second: 15 fps @ 8MP, 20 fps @ 6MP, 25 fps @ 4MP
- 4-in-1 output switchable via DIP switch
- Day/night mode with removable mechanical filter (ICR)
- 0.005 lux F1.6 (color) / 0 lux IR On
- Smart IR: 1 LED, up to 30 meters
- 2.8mm fixed lens
- Viewing angle: 110.8° (H)
- OSD via coaxial (8MP video up to 700 meters)
- Imaging modes: BLC, HLC, WDR 120dB, 2D/3D-NR
- Automatic and manual white balance
- Automatic gain control
- 1 audio interface
- Power supply: 12V DC (±30%)
- Consumption: 7W (max.)
- Storage temperature -30° C ~ +60° C
- -30° C ~ +60° C operating temperature
- Relative humidity: <90% (non-condensing)
- IP67 protection rating
- IK10 vandal protection
- Aluminum casing
- Dimensions: Ø122 x 88.9 mm
- Weight: 410g
- 3AXIS: 0° ~ 355° (PAN), 0° ~ 75° (TILT), 0° ~ 355° (Rotation)
