Description

![]()

Features
- 1/2.7" 5-megapixel CMOS sensor
- Digital resolution: 5MP (2880x1620), 4MP (2560x1440), 1080P (1920x1080), 960H (960x756)
- Frames per second: 25 fps at 5MP (CVI), 25 fps at 4MP (CVI/TVI/AHD), 25 fps at 1080P (CVI)
- 4-in-1 output switchable via OSD
- Day/night mode with removable mechanical filter (ICR)
- 0.005 lux F1.6 (color) / 0 lux IR on
- Smart IR: 2 LEDs, up to 80 meters
- Fixed 2.8mm lens
- Viewing angle: 111° (H), 58° (V), 132° (D)
- OSD via coaxial (5MP video up to 700 meters)
- Imaging modes: BLC, HLC, digital WDR, 2D-NR, mirror
- Automatic and manual white balance
- Automatic and manual gain control
- Supports 8-zone privacy mask
- Built-in microphone
- Power supply: 12V DC (±30%)
- Consumption: 5.2W (max.)
- Storage temperature -40°C ~ +60°C
- -40°C ~ +60°C operating temperature
- Relative humidity: <95% (non-condensing)
- IP67 protection rating
- Metal and plastic housing
- Dimensions: 80.2 (L) x 76.2 (H) x 198.9 mm
- Weight: 270g
- 3AXIS: 0° ~ 360° (PAN), 0° ~ 90° (TILT), 0° ~ 360° (Rotation)
