Description
Specifications
- 1/3" 4-megapixel CMOS image sensor
- Resolution: 4MP (2688x1520), 3MP (2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- H.265+, H.265, H.264+, and H.264 video compression
- Stream 1: 4MP (1 ~ 25 fps)
- Stream 2: D1 (1 ~ 25 fps)
- Stream 3: 720P (1 ~ 25 fps)
- Day/night mode with removable mechanical filter (ICR)
- 0.08 lux F2.0 (color, 1/3 s), 0.3 lux F2.0 (color, 1/30 s), 0 lux IR on
- Smart IR: 2 LEDs, up to 30 meters
- 2.8mm fixed lens
- Viewing angle: 104° (H), 55° (V), 125° (D)
- 16X digital zoom
- Imaging modes: BLC, HLC, WDR 120dB, 3D-DNR, mirror
- White balance with 5 modes
- Automatic and manual gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI), and 4-zone privacy mask
- Smart Video Detection (IVS): Line crossing detection, intrusion detection, abandoned/lost object detection
- Face detection
- 1 audio input / 1 output
- 1 alarm input / 1 output
- MicroSD card slot up to 128 GB (card not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: HTTP, HTTPs, TCP, ARP, RTSP, RTP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, QoS, UPnP, NTP, Bonjour, 802.1x, Multicast, ICMP, IGMP, SNMP
- Remote viewing with browsers (IE, Chrome, Firefox, and Safari) and IOS and Android smartphones
- Intelligent management software PSS, DSS, and Easy4ip
- Interoperability: ONVIF, PSIA, CGI
- Power: 12V DC
- Consumption: <6.5W
- Supports PoE (802.3 af, Class0)
- Storage conditions: -40°C ~ +70°C, relative humidity <95%
- Operating conditions: -40°C ~ +70°C, relative humidity <95%
- IP67, IP6K9K protection rating
- IK10 vandal protection
- Metal casing
- Dimensions: 112.9 (L) x 69.4 (H) x 136.3 mm
- Weight: 590 g
- 3AXIS: 0° ~ 20° (PAN), ±15° (TILT), 0° ~ 360° (Rotation)
- Compliant with vehicle standard requirements such as EN50155, E-MARK (ECE Regulation No. 10)
- Charger not included
