Description
Features
- Sony® STARVIS™ 1/2.8” 2-megapixel CMOS sensor
- H.264 and H.265 encoding with triple stream
- 1080P (1920x1080) resolution at 25 fps
- 120dB WDR, day/night with ICR filter, 3D-DNR, AWB, AGC, BLC
- Multiple remote monitoring via web browser, CMS (DSS/PSS) and DMSS
- 2.7~13.5mm motorized lens
- Smart IR up to 40 meters
- 1 alarm input / 1 output
- 1 audio input / 1 output
- MicroSD slot
- Supports PoE / ePoE
Specifications
- Sony® STARVIS™ 1/2.8” 2-megapixel CMOS sensor
- Compression formats: H.265 / H.264 / MJPEG
- Digital resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 1080P (1 ~ 25/30 fps)
- Stream 2: D1 (1 ~ 25/30 fps)
- Stream 3: 1080P (1 ~ 6 fps)
- Day/night mode with removable mechanical filter
- Smart IR: 3 LEDs, 40 meters
- 0.002 lux F1.5
- 2.7~13.5mm motorized lens
- Viewing angle: 109° ~ 30° (H), 57° ~ 17° (V)
- White balance: automatic, natural, street light, outdoor, manual
- Automatic and manual gain control
- Backlight compensation: BLC, HLC
- 120dB WDR
- 3D-DNR digital noise reduction
- 4 ROI zones
- 4-zone rectangular video sensor
- 4-zone rectangular privacy mask
- EIS image stabilizer
- Defog
- Mirror mode
- Artificial intelligence:
- Face detection: enhancement; snapshot; high quality image reports; face exposure; facial attribute extraction
- Face attributes: supports 6 types of facial attribute extraction and 8 expressions, such as age, gender, expressions (anger, calm, joy, sadness, disgust, surprise, confusion, fear), mouth mask,
beard, mustache, etc. - Perimeter protection: line crossing, intrusion, rapid movement (all three functions support people/vehicle classification), loitering detection, people gathering, parking detection
- People counting: supports counting entry number, license number and pass number and displays/generates annual/monthly/daily reports. Supports counting numbers in the area and defining 4 rules. Count the number of people or stay time and link the alarm. Supports queue management and 4 rule configuration
- Intelligent Detection (IVS): abandoned/lost objects, heat map
- 1 audio input / 1 output
- 2 alarm inputs / 1 output
- MicroSD card slot up to 256GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, HTTPS, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, 802.1x, SNMP
- Compatible with ONVIF (Profile S / G / T), CGI, Milestone, P2P, SDK, API
- Up to 20 users
- Remote viewing via IE8 +, Chrome, Firefox and Safari + 12 browsers
- Intelligent management software PSS, DSS, DMSS
- Compatible with IOS and Android mobile devices
- Power supply: 12V DC (± 30%)
- Consumption: <10.6 W
- Supports PoE (802.3 af, class 0)
- Supports ePoE: full-duplex transmission of more than 800 meters at 10 Mbps or 300 meters at 100 Mbps via Cat5 or coaxial cable
- Not suitable for outdoor use
- Storage temperature -40°C ~ + 60°C
- -30°C ~ + 60°C operating temperature
- Relative humidity: <95%
- Plastic casing
- Dimensions: Ø180.5 x 131.4 mm
- Weight: 510g
- 3AXIS: 0° ~ 355° (PAN), 0° ~ 75° (TILT), 0° ~ 355° (Rotation)
- Does not include charger
