Description
- 1/1.8" Sony® STARVIS™ 8-megapixel CMOS sensor
- Smart H.265, Smart H.264, H.265, H.264 compression formats
- Resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 1080P, 1.3MP, 720P (1~25/30fps)
- Stream 2: D1, VGA, CIF (1~25/30fps)
- Stream 3: 1080P, 1.3MP, 720P (1~25/30fps)
- Day/night mode with removable mechanical filter
- Infrared illumination: 8 LEDs, up to 400 meters
- 0.005 lux F1.4 (color), 0.0005 lux F1.4 (B/W), 0 lux IR on
- 60X optical zoom: 5.6 ~ 336 mm
- Viewing angle: 56.4°~1.2°(H), 32.7°~0.7°(V), 63.6°~1.7°(D)
- Automatic, semi-automatic and manual focus control
- 16X digital zoom Image modes: BLC, HLC, WDR 120dB, 2D/3D-NR,
- Digital defog
- Image modes: BLC, HLC, WDR 120 dB, 2D/3D-NR, optical defog
- White balance with 8 modes
- Automatic and manual gain control
- Supports video sensor and regions of interest (ROI)
- Privacy masking up to 24 zones with 8 zones on a single screen
- Video metadata: supports attribute capture and extraction from images of human bodies, human faces, motor and non-motor vehicles
- Perimeter protection with line crossing detection, intrusion detection, fence climbing detection, loitering detection, abandoned/missing object detection, rapid movement detection, parking detection, people gathering detection and vehicle/person alarm classification
- Face recognition
- Horizontal positioner: 0° ~ 360° continuous
- Vertical positioner: -45° ~ 90°
- Manual speed: 0.1° ~ 160°/sec. (H), 0.1° ~ 60°/sec. (V)
- Preset speed: 160°/sec. (H), 60°/sec. (V)
- 300 presets with DH-SD and Pelco-D/P protocols with automatic recognition
- 8 tours (up to 32 presets per tour)
- 5 patterns and 5 scans
- 1 RS485 port
- 1 BNC video output
- Two-way audio
- 1 audio input / 1 audio output
- 7 alarm inputs / 2 alarm outputs
- MicroSD card slot up to 512GB (card not included)
- Network interface: RJ45 (10/100Base-T)
- Network protocols: HTTP, HTTPS, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, IPv6, 802.1x, QoS, FTP, UPnP, ICMP, SNMP, IGMP, RTP, PPPoE, RTMP, TCP
- ONVIF (Profile S/G/T) compliance, CGI
- Unicast/Multicast streaming method
- Up to 20 users
- Remote viewing via IE7, Chrome, Firefox and Safari browsers
- Smart PSS, DSS, IVSS management software
- Compatible with IOS and Android mobile devices
- Power supply: 36V DC /5A (±25%)
- Consumption: 22W (basic), 63W (maximum)
- Operating temperature -40°C ~ +70°C
- Relative humidity: ≤ 95%
- IP67 protection rating
- Lightning-proof 6KV
- Lens cleaning
- Dimensions: 210.7 (W) x 517 (H) 399.3 mm
- Weight: 15.4 kg
- Includes power supply
