Description
- 1/2.8" 4-megapixel Sony Starvis™ CMOS image sensor
- Smart H.265+, Smart H.264+, H.265, H.264, and MJPEG video compression
- Resolution: 4MP (2560x1440), 3MP (2048x1536, 2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576, 704x480), VGA (640x480), CIF (352x288, 352x240)
- Stream 1: 4MP, 3MP, 1080P, 1.3MP, 720P (1~25/30 fps)
- Stream 2: D1, VGA, CIF (1~25/30 fps)
- Stream 3: 1080P, 1.3MP, 720P (1~25/30 fps)
- Day/night mode with electronic filter
- 0.005 lux F1.6 (color), 0.0005 lux F1.6 (B/W), 0 lux IR On
- Smart IR: 7 IR LEDs, up to 300 meters
- 45X optical zoom: 3.95 ~ 177.7mm
- Viewing angle: 63.2°~1.8°(H), 37.6°~1.1°(V), 70.8°~2.1°(D)
- Auto, semi-auto, and manual focus
- 16X digital zoom
- Image modes: BLC, HLC, WDR 120dB, 2D/3D-NR, Digital Defog
- White balance with 8 modes
- Automatic, manual, and priority gain control
- Supports video sensor and regions of interest (ROI)
- Privacy masking up to 24 zones with 8 zones on a single screen
- Perimeter protection: line crossing, intrusion, fence climbing, loitering detection, abandoned/missing object, fast movement, parking detection, crowd gathering, vehicle/person alarm classification
- Face detection
- Integrated auto-tracking
- SMD 4.0
- Horizontal positioner: 0° ~ 360° continuous
- Vertical positioner: -20° ~ 90°, auto-flip 180°
- Manual speed: 0.1° ~ 200°/sec (H), 0.1° ~ 120°/sec (V)
- Preset speed: 240°/sec (H), 200°/sec (V)
- 300 presets, DH-SD and Pelco-D/P protocols with auto recognition
- 8 tours (up to 32 presets per tour)
- 5 patterns and 5 scans
- RS485 port
- 1 audio input / 1 audio output
- 7 alarm inputs / 2 alarm outputs
- MicroSD card slot up to 512GB (card not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: FTP, RTMP, IPv6, Bonjour, IPv4, DNS, RTCP, PPPoE, NTP, RTP, 802.1x, HTTPS, SNMP, TCP/IP, DDNS, UPnP, NFS, ICMP, UDP, IGMP, SMB, HTTP, SSL, DHCP, SMTP, QoS, RTSP, ARP
- ONVIF (S/G/T), CGI, SDK support
- Up to 20 users
- DMSS and DSS Pro management software
- Compatible with IOS and Android devices
- Supports IE, Chrome, Firefox, and Safari browsers
- Power supply: 36V DC, 2.23A (±25%) / Hi-PoE
- Power consumption: 13W (basic), 27W (illuminator + positioner)
- Operating temperature: -40°C ~ +70°C
- Relative humidity ≤95%
- IP67 degree of protection
- 6KV lightning protection
- Includes lens wiper
- Dimensions: Ø239.8 x 382 (H) mm
- Gross weight: 6.8 kg
- Net weight: 9.2 kg
- Includes wall mount and power supply
