Description
1/3" 4 megapixel CMOS sensor
Compression formats: Smart H.265+, Smart H.264+, H.265, H.264, MJPEG
Digital resolution: 4MP (2688x1520), 4MP (2560x1440), 3MP (2048x1536), 3MP (2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
Stream 1: 4MP (1~25/30 fps)
Stream 2: D1 (1~25/30 fps)
Stream 3: 1080P (1~25/30 fps)
Day/night mode with removable mechanical filter
Smart IR: 2 IR LEDs, 30 meter range
0.005 lux F1.4 (color), 0.0005 lux F1.4 (B/W), 0 lux IR On
2.8 mm fixed lens
Viewing angle: 102°(H), 54°(V), 121°(D)
Imaging modes: BLC, HLC, WDR 120dB, 3D-NR, AFSA, Mirror, Defog
White balance with 6 modes
Automatic gain control
Support for 4-zone video sensor, 4 regions of interest (ROI) and 4-zone privacy mask.
Perimeter protection with cross-line detection and intrusion detection (both modes support person/vehicle classification)
Built-in microphone
1 RCA audio input / 1 RCA audio output
1 alarm input / 1 alarm output
MicroSD card slot up to 256 GB (not included)
Network interface: RJ45 (10/100 Base-T)
Network protocols: IPv4, IPv6, HTTP;TCP, UDP, ARP, RTP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP
ONVIF (Profile S/G/T), CGI, P2P, Milestone, Genetec, SDK, API support
Up to 20 users
Remote viewing via IE11, Chrome and Firefox browsers
Smart PSS, DSS, DMSS management software
Compatible with IOS and Android mobile devices
Power supply: 12V DC / PoE (802.3af)
Maximum power consumption: 5.9W (12V) / 7.2W (PoE)
Storage temperature: -40°C ~ +60°C
Operating temperature: -40°C ~ +60°C (-40°C ~ +60°C)
Relative humidity: <95%.
IP67 protection rating
IK10 vandal protection
Metal housing
Dimensions: Ø111 x 64.8 (H) mm
Weight: 423 g
-
3AXIS: 0°~355°(PAN), -20°~70°(TILT), 0°~355°(Rotation)
