Description
Features
- Sony® STARVIS™ 2 megapixel 1/2.8" CMOS sensor
- 3x optical zoom
- Starlight technology
- 1080P (1920x1080) at 25 fps
- H.265 compression format
- WDR 120dB, day/night with ICR filter, 2D/3D-DNR
- Infrared range up to 20 meters
- IVS Intelligence
- WiFi support
- IP66 protection rating
Specifications
- Sony® STARVIS™ 2 megapixel 1/2.8" CMOS sensor
- H.265+/H.265/H.264+/H.264/MJPEG compression formats
- Digital resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), CIF
- (352x288)
- Stream 1: 1080P, 1.3MP, 720P (1~25 fps)
- Stream 2: D1, CIF (1~25 fps)
- Stream 3: 720P, D1, CIF (1~25 fps)
- Day/night mode with removable mechanical filter
- Infrared illumination: 1 led, 20 meters
- Minimum illumination: 0.005 lux F1.8 (color) / 0.0005 lux F1.8 (B/W), 0 lux IR On
- Optical zoom: 2.7~8.1mm
- Viewing angle: 46.43°~106.79° (H), 25.91°~57.88° (V)
- Autofocus, semi-automatic and manual control
- 16X digital zoom
- White balance: Automatic, Indoor, Outdoor, Tracking, Manual, Sodium lamp, Natural light, Street light
- Automatic and manual gain control
- Backlight compensation (BLC, HLC)
- True WDR (120 dB)
- 2D and 3D noise reduction
- Digital defogging
- Digital Image Stabilizer (EIS)
- ROI support
- Video sensor support
- IVS Intelligence: line crossing, intrusion, abandoned/lost objects
- Advanced intelligence: facial detection, heat map
- Horizontal positioner: 0°~180° continuous
- Vertical positioner: -5°~-55°
- Manual speed: 6°/sec. (H), 3°/sec. (V)
- 1 audio input / 1 audio output
- MicroSD card slot up to 256GB (card not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, SNMPv1/v2c/v3 (MIB-2), ARP, RTCP, RTCP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
- Compatible with ONVIF, CGI
- Unicast/multicast streaming method
- Up to 20 users
- Remote viewing with IE7, Chrome42, Firefox52, Safari browsers
- Smart Player, configuration software, Smart PSS, DMSS, DSS
- Power supply: 12V DC / 1.5A (7W, 11W with IR illumination activated)
- Supports IEEE802.11b/g/n WiFi standard
- Operating temperature from -30°C to +60°C
- Humidity: <95%
- IP66 protection rating
- 4KV lightning resistant
- ADC12 aluminum housing
- Dimensions: Ø90 (L) x 102.7 (H) x 195.3 mm
- Weight: 900 g
