Description
Features
- 4-megapixel 1/1.8" CMOS sensor
- H.265 and H.264 encoding with triple stream
- 4MP (2688x1520) resolution at 25 fps, 1080P (1920x1080) at 50 fps
- 140dB WDR, day/night with electronic filter, 3D-DNR, AWB, AGC, BLC
- Multiple remote monitoring via web browser, CMS (DSS/PSS), and DMSS
- 2.8 mm fixed lens
- White LEDs with a range of up to 20 meters
- Integrated microphone
- MicroSD slot
- IP67 protection rating
- PoE support
Specifications
- 4-megapixel 1/1.8" CMOS sensor
- Compression formats: H.265+/H.265/H.264+/H.264/MJPEG
- Digital resolution: 4MP (2688x1520), 4MP (2560x1440), 3MP (2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CGA (352x288)
- Stream 1: 4MP (1 ~ 25 fps), 1080P (1 ~ 50 fps)
- Stream 2: D1 (1 ~ 20 fps), D1 (1 ~ 50 fps)
- Stream 3: 1080P (1 ~ 16 fps)
- Day/night mode with electronic filter
- 2 white LEDs, 20 meters
- 0.001 lux F1.6
- 2.8 mm fixed lens
- Viewing angle: 113° (H), 60° (V)
- White balance: Auto, Natural, Streetlight, Outdoor, Manual
- Automatic and manual gain control
- Backlight compensation: BLC, HLC
- 140dB WDR
- 3D-DNR digital noise reduction
- 4 ROI zones
- Video sensor with 4 rectangular zones
- Masking with 4 rectangular zones
- Defog
- Mirror mode
-
Artificial Intelligence:
- Face capture: supports face image captures
- Perimeter protection: line crossing, intrusion (people/vehicle classification)
- People counting: supports line crossing, region crossing counts
- Supports 4 independent detection accesses and 4 independent detection zones
- Intelligent detection (IVS): scene changes, abandoned/lost objects
- Integrated microphone
- MicroSD card slot up to 256 GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/v6, SNMP, QoS, UPnP, NTP, ICMP, HTTPS, IGMP, 802.1x
- Compatible with ONVIF (profile S/G), CGI, Milestone, P2P
- Unicast/Multicast streaming method
- Up to 20 users
- Remote viewing via IE, Chrome, Firefox, and Safari browsers
- Smart PSS, DSS, P2P management software
- Compatible with IOS and Android mobile devices
- Power: 12V DC
- Consumption: <7.2W
- PoE support (802.3 af, class 0)
- IP67 protection rating
- Storage temperature from -30°C to +60°C
- Operating temperature from -30°C to +60°C
- Humidity: 10% ~ 95%
- Metal casing
- Dimensions: Ø106 x 99.2 (H) mm
- Weight: 550 g
- 3AXIS: 0° ~ 360° (PAN), 0° ~ 78° (TILT), 0° ~ 360° (rotation)
- Does not include power supply
