Description
Features
- 2 megapixel 1/2.8" Sony® STARVIS™ CMOS sensor
H.265/H.264 encoding with triple stream
1080P at 25 fps
WDR 120dB, electronic day/night filter, 3D DNR, AWB, AGC, BLC
Multiple IP surveillance: Web viewer, CMS (DSS/PSS) and DMSS
2.8mm fixed lens
White LEDs with a range of up to 25 meters
Two-way audio
1 alarm input / 1 alarm output
MicroSD slot, IP67, PoE
Specifications
- 2 megapixel 1/2.8" Sony® STARVIS™ CMOS sensor
- Compression formats: H.265+/H.265/H.264+/H.264/MJPEG
- Digital resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 1080P (1 ~ 25 ips)
- Stream 2: D1 (1 ~ 25 ips)
- Stream 3: 1080P (1 ~ 6 ips)
- Day/night mode with electronic filter
- 2 white LEDs, 25 meters
- 0.002 lux F1.6
- 2.8mm fixed lens
- Viewing angle: 106° (H); 57° (V)
- White balance: Auto, Natural, Street Light, Outdoor, Manual
- Gain control: Auto, Manual
- Backlight compensation (BLC, HLC)
- Real WDR 120dB
- 3D-DNR digital noise reduction
- 4 ROI zones
- Video sensor with 4 rectangular zones
- Masking of 4 rectangular zones
- Mirror mode, defogging
- Artificial Intelligence:
- Facial capture: Supports facial image capture
- Perimeter protection: line crossing, intrusion (person/vehicle classification)
- People counting: Supports line crossing, region crossing, people queues
- Allows 4 independent detection accesses and 4 independent detection zones
- IVS Intelligence: Detection of abandoned/lost objects, detection of scene changes
- 1 audio input / 1 audio output
- 1 alarm input / 1 alarm output
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/v6, SNMP, QoS, UPnP, NTP, ICMP, HTTPS, IGMP, 802.1x
- Compatible with ONVIF (Profile S/G), CGI, Milestone, P2P
- Unicast/multicast streaming method
- Up to 20 users
- Remote viewing via IE, Chrome, Firefox and Safari browsers
- Smart PSS, DSS, DMSS management software
- Compatible with IOS and Android mobile devices
- MicroSD card slot up to 256GB (card not included)
- Power supply: 12V DC
- Consumption: <7W
- Supports PoE (802.3 af, Class 0)
- IP67 protection rating
- Operating temperature from -30°C to +60°C
- Humidity: 10% ~ 95%
- Metal casing
- Dimensions: 709 (L) x 75.9 (H) x 244.1 mm
- Weight: 815 g
- 3AXIS: 0° ~ 360° (PAN), 0° ~ 90° (Tilt), 0° ~ 360° (Rotation)
- Power supply sold separately
