Description
Features
- 1 / 2.8 "3 megapixel STARVIS ™ CMOS sensor
- Triple stream and H.265 + / H.265 / H.264 + / H.264 encoding
- 3MP (2048x1536) resolution up to 25 fps
- Supports intelligent detection
- WDR 120 dB, day / night with ICR filter, 3D-DNR, AWB, AGC, BLC
- Multiple remote monitoring via web browser, CMS (DSS / PSS) and DMSS
- Fixed 1.85mm optics
- LDC lens distortion correction function
- Infrared illumination up to 15 meters
- 1 audio input / 1 audio output
- 1 alarm input / 1 alarm output
- IP67 degree of protection
- IK10 vandal resistant
- MicroSD slot, PoE
Specifications
- 1 / 2.8 "3 megapixel STARVIS ™ CMOS sensor
- Compression formats: H.265 + / H.265 / H.264 + / H.264 / MJPEG
- Digital resolution: 3MP (2048x1536), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), CIF (352x288)
- Stream 1: 3MP (1 ~ 25 fps)
- Stream 2: D1 (1 ~ 25 fps)
- Stream 3: 1080P (1 ~ 25 fps)
- Day / night mode with removable mechanical filter
- Smart IR: 3 led array, 15 meters
- 0.006 lux F2.0 (color, 1/3 s, 30IRE), 0.03 lux F2.0 (color, 1/30 s, 30IRE), 0 lux F2.0 (IR activated)
- Fixed 1.85mm optics
- LDC function for corrective lens distortion
- Viewing angle with LDC activated: 151 ° (H), 114 ° (V)
- Viewing angle with LDC disabled: 166 ° (H), 121 ° (V)
- 16X digital zoom
- White Balance: Auto, Natural, Street Light, Outdoor, Manual
- Automatic and manual gain control
- Backlight compensation: BLC, HLC
- WDR 120dB
- 3D-DNR digital noise reduction
- 4 zones of return on investment
- Video sensor with 4 rectangular zones
- Privacy mask with 4 rectangular zones
- Mirror mode
- Smart detection (IVS): line crossing detection, intrusion detection, abandoned / lost object detection
- Facial detection
- Video interface (for settings only)
- 1 audio input / 1 audio output
- 1 alarm input (5V DC / 5 mA)
- 1 alarm output (12V DC / 0.3A)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: HTTP, HTTPs, TCP, ARP, RTSP, RTP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4 / v6, QoS, UPnP, NTP, Bonjour, 802.1x, Multicast, ICMP, IGMP , SNMP
- Compatible with ONVIF, PSIA, CGI
- Unicast / multicast streaming method
- Up to 10/20 users
- Remote viewing via IE, Chrome, Firefox and Safari browsers
- Smart PSS, DSS, Easy4ip management software
- Compatible with IOS and Android mobile devices
- MicroSD card slot up to 128 GB (card not included)
- Power supply: 12V DC, 24V AC
- Consumption: <9W
- PoE support (802.3 af, Class0)
- IP67 degree of protection
- IK10 vandal protection
- Storage temperature from -30 ° C to + 60 ° C
- Operating temperature from -30 ° C to + 60 ° C
- Humidity: <95%
- Metal casing
- Dimensions: Ø159.1 x 117.9 mm
- Weight: 1.15 kg
- 3AXIS: 0 ° ~ 355 ° (PAN), 0 ° ~ 65 ° (TILT), 0 ° ~ 355 ° (Rotation)
- Does not include power supply
