Description
Specifications
- 1/2.8” 2-megapixel CMOS sensor
- Compression formats: H.265+ / H.265 / H.264+ / H.264 / MJPEG
- Digital resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), CIF (352x288)
- Stream 1: 1080p (1 ~ 25 fps)
- Stream 2: D1 (1 ~ 25 fps)
- Stream 3: 1080P (1 ~ 25 fps)
- Day/night mode with removable mechanical filter
- Smart IR: 3 LEDs array, 50 meters
- Minimum illumination: 0.006 lux F1.6 (color, 1/3 s, 30IRE), 0.05 lux F1.6 (color, 1/30 s, 30IRE), 0 lux F1.6 (IR on)
- 2.7 ~ 13.5 mm motorized lens
- Viewing angle: 101° ~ 31° (H), 54° ~ 17° (V)
- 16X digital zoom
- White balance: auto, natural, street lamp, outdoor, manual
- Automatic and manual gain control
- Backlight compensation (BLC, HLC)
- Real WDR 120dB
- 3D digital noise reduction
- 4 ROI zones
- Video sensor with 4 rectangular zones
- Masking of 4 rectangular zones
- Mirror mode
- Smart Video Detection (IVS): line crossing, intrusion, abandoned/lost objects
- Facial detection
- HDMI video interface (1.4a)
- 1 audio input / 1 output
- 1 alarm input (5V DC / 5 mA)
- 1 alarm output (12V DC / 300 mA)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: HTTP, HTTPs, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, QoS, UPnP, NTP, Bonjour, IEEE 802.1x, Multicast, ICMP, IGMP, SNMP, TLS
- Compatible with ONVIF (S/G), API
- Unicast/multicast streaming method
- Up to 10/20 users
- MicroSD card slot up to 128GB (card not included)
- Power: 12V DC, 24V AC
- Consumption: <4.4 W
- PoE+ (802.3 class 4) support / 11.8 W
- ePoE support: full-duplex transmission over 800 meters at 10 Mbps or 300 meters at 100 Mbps via Cat5 or coaxial cable
- 6KV lightning resistant
- IP67 degree of protection
- IK10 vandal protection
- Storage temperature from -30 °C to +60 °C
- Operating temperature from -30 °C to +60 °C
- Humidity: <95%
- Metal casing
- Dimensions: Ø159.1 x 117.9 mm
- Weight: 950 g
- 3AXIS: 0° ~ 355° (PAN), 0° ~ 65° (TILT), 0° ~ 355° (rotation)
- Power supply not included
