Description
- 16 IP channels
- Video compression: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
- 2 VGA video outputs and 2 HDMI (4K) outputs:
- Heterogeneous video source output for HDMI 1 and HDMI 2
- Simultaneous video source output for VGA 1 and HDMI 1
- Simultaneous video source output for VGA 2 and HDMI 2
- Main screen output division: 1, 4, 8, 9, 9, 16
- Secondary display output division: 1, 4, 8, 8, 9, 16
- 1 RCA audio input / 2 outputs
- Audio compression: PCM, G.711a, G.711u, G726
- Recording resolution: 32MP, 24MP, 16MP, 12MP, 8MP, 5MP, 4MP, 1080P, 720P, D1, CIF, QCIF
- Bandwidth with AI disabled: 384 Mbps input, 384 Mbps recording, 384 Mbps output
- Bandwidth with AI enabled: 200 Mbps input, 200 Mbps recording, 200 Mbps output
- AI decoding capacity disabled: 2 channels at 32MP (20 fps), 2 channels at 24MP (20 fps), 4 channels at 16MP (30 fps), 5 channels at 12MP (30 fps), 8 channels at 8MP (30 fps), 12 channels at 5MP (30 fps), 16 channels at 4MP (30 fps)
- AI-enabled decoding capacity: 1 channel at 32MP (20 fps), 1 channel at 24MP (20 fps), 2 channels at 16MP (30 fps), 4 channels at 12MP (30 fps), 4 channels at 8MP (30 fps), 8 channels at 5MP (30 fps), 12 channels at 4MP (30 fps)
- General, motion detection, intelligence, alarm, and POS recording modes
- Video sensor alarm, privacy mask alarm, local alarm
- AI on recorder:
- Perimeter protection up to 4 channels with 10 IVS rules per channel
- Face detection with attributes up to 2 channels and up to 12 frames per second per channel
- Face recognition with attributes up to 2 channels, up to 12 frames per second and up to 20 databases with 20,000 images
- SMD Plus up to 8 channels with filtering between people and vehicles
- AI support for compatible IP cameras
- Supports up to 16 IP cameras with perimeter protection.
- Supports up to 16 IP cameras with face detection
- Supports up to 16 IP cameras with face recognition
- Supports up to 16 IP cameras with SMD Plus
- Supports up to 8 IP cameras with video metadata
- Supports up to 8 IP cameras with ANPR (up to 20,000 license plates with whitelist/blacklist)
- Maximum 16 channel playback
- 16 alarm inputs / 6 alarm outputs
- Internal capacity for 4 SATA hard drives up to 16TB (sold separately)
- eSATA port
- 2 RJ45 Fast Ethernet network ports (10/100/1000Mbps)
- Network protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP filtering, PPPoE, FTP, DDNS, alarm server, IP search (supports Dahua IP cameras, DVR, NVS, etc.), Multicast, P2P, Auto Logging
- ONVIF 22.06 (Profile T/S/G), CGI and SDK support
- Compatible with web browsers, Android and iOS devices
- Local and Internet network server access
- Ability to limit user access to cameras in local and/or remote mode
- Can be remotely controlled via a Joystick keyboard connected via TCP/IP
- Email sending with attached photo in case of alarm
- Sending to a scheduled or alarm FTP
- Ability to send an alarm, and be connected to a video surveillance reception software
- Ability for fixed or dynamic IP via Dyndns, NoIP, DDNS Evolution, etc. service
- Communication ports: 1 x USB 2.0 port, 2 x USB 3.0 ports, 1 x RS232 port, 1 x RS485 port
- Power supply: 100V ~ 240V AC, 50/60Hz
- Power consumption: ≤13W (without disks)
- Storage temperature: -20°C ~ +60°C
- Operating temperature: -10°C ~ +55°C
- Relative humidity 10%~93%.
- Dimensions: 440 (W) x 70 (H) x 415.1 mm
- Net weight: 4.74 kg
- Gross weight: 6.11 kg
- Rack or desktop installation
