Description
- 4 IP channels
- Video compression: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
- Simultaneous HDMI (4K) and VGA (1080P) video outputs
- Display division: 1, 4
- 1 RCA audio input / 1 RCA audio output
- Audio compression: PCM, G.711a, G.711u, G726
- Recording resolution: 12MP, 8MP, 5MP, 4MP, 3MP, 1080P, 720P, D1
- Bandwidth: 80 Mbps for access, 80 Mbps for recording, 60 Mbps for sending
- Decoding capability with AI disabled: 1 channel at 12MP (30 fps), 1 channel at 8MP (30 fps), 2 channels at 5MP (30 fps), 3 channels at 4MP (30 fps), 6 channels 1080P (30 fps)
- Decoding capability with AI enabled: 1 channel at 8MP (30 fps), 1 channel at 5MP (30 fps), 2 channels at 4MP (30 fps), 4 channels 1080P (30 fps)
- Recording modes: manual recording, alarm recording, motion detection recording, scheduled recording.
- AI on the recorder:
- 1-channel perimeter protection
- Face detection with attributes on 1 channel and up to 12 frames per second per channel
- Face recognition with attributes on 1 channel, up to 4 frames per second and up to 10 databases with 5000 images
- SMD Plus up to 4 channels with filtering between people and vehicles
- AI support by compatible IP cameras:
- Supports up to 4 IP cameras with perimeter protection.
- Supports up to 5 IP cameras with face detection.
- Supports up to 5 IP cameras with face recognition
- Supports up to 6 IP cameras with SMD Plus
- Playback up to 4 channels
- Internal capacity for 1 SATA hard drive up to 10 TB (sold separately)
- RJ45 Fast Ethernet network port (10/100 Mbps)
- Network protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, NTP, DHCP, DNS, SMTP, UPnP, IP filtering, DDNS, alarm server, IP search (supports Dahua IP cameras, DVR, NVS, etc.), P2P, auto recording
- ONVIF (Profile T/S/G), CGI and SDK support
- Compatible with web browsers, Android and iOS devices
- Local network and internet server access
- Ability to limit user access to cameras in local and/or remote mode
- Can be remotely controlled via a Joystick keyboard connected via TCP/IP
- Sending emails with attached photo in case of alarm
- Sending to an FTP scheduled or on alarm
- Ability to send an alarm, and be connected to a video surveillance reception software.
- Ability for fixed or dynamic IP via Dyndns, NoIP, DDNS Evolution, etc. service.
- Communication ports: 2 USB 2.0 ports
- Power supply: 12V DC, 1.5A
- Power consumption: ≤10W (excluding disks)
- Storage temperature: 0°C ~ +40°C
- Operating temperature: -10°C ~ +55°C
- Relative humidity 10%~93%.
- Dimensions: 260 (W) x 47.6 (H) x 232.7 mm
- Net weight: 810 g
- Gross weight: 1.38 kg
- Tabletop installation
