Description
- 2 megapixel 1/2.8" CMOS sensor
- Compression formats: Smart H.265+, Smart H.264+, H.265, H.264, MJPEG
- Digital resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 1080P (1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Day/night mode with removable mechanical filter
- Smart IR: 4 leds, 60 meter range
- 0.002 lux F1.5 (color), 0.0002 lux F1.5 (B/W), 0 lux IR On
- 2.7 ~ 13.5 mm motorized lens
- Viewing angle: 108°~30°(H), 56°~17°(V), 131°~35°(D)
- Image modes: BLC, HLC, WDR 120dB, 3D-NR, Mirror
- White balance with 6 modes
- Automatic and manual gain control
- Support for 4-zone video sensor, 4 regions of interest (ROI), and 4-zone privacy mask
- Perimeter protection with cross-line detection and intrusion detection (both modes support human/vehicle classification)
- SMD Plus
- Built-in microphone
- MicroSD card slot up to 256GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP, P2P
- ONVIF (Profile S/T), CGI, SDK and API support
- Up to 6 users
- Remote viewing via IE, Chrome and Firefox browsers
- SmartPSS Lite, DSS, DMSS management software
- Compatible with IOS and Android mobile devices
- Power supply: 12V DC / PoE (802.3af)
- Power consumption: 8.5W (12V) / 9.8W (PoE)
- Storage temperature: -40°C ~ +60°C
- Operating temperature: -30°C ~ +60°C
- Relative humidity: ≤95%.
- IP67 protection rating
- Metal housing
- Dimensions: 90.7 (L) x 90.7 (H) x 238.5 mm
- Net weight: 760 g
- Gross weight: 1.02 kg
- 3AXIS: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(Rotation)
